| 勾选 | 型号 | 产品类型 | 显示内容 | 产品图 |
外形尺寸 (mm) |
视域窗口尺寸 (mm) |
显示尺寸 mm/英寸 |
点间距 mm |
视角 | 背光类型或亮度 | 连接方式PIN数 | 接口方式 | 特殊说明 | 工作温度 | 供电电压 | IC芯片型号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 132*64 COG点阵液晶屏HTG13264C显示屏 | COG | 132x64 |
|
57.5x41.7x2.0 | 54.0x30.2 | 48.81x26.21 | 0.41x0.37 | 6H | 白光 | FPC-28PIN | MCU | -20~70℃ | 3.3v | ST7565R | ||
| 160x160 COG点阵液晶屏/工业计量仪显示屏/HTG160160L-31W-34C05-V01 | COG | 160x160 |
|
88.0x93.0x5.2 | 84x81.5 | 75.18x75.18 | 0.47x0.47 | 6H | 34pin | MCU | 抗静电ESD 8KV | -20~70℃ | 3.3V | UC1698 | ||
| 160x32 COG点阵液晶屏/HTG16032G | COG | 160x32 |
|
91.2x31.2x5.0 | 83.0x21.2 | 75.16x16.0 | 0.47x0.47 | 6H | 白光 | FPC-22PIN | MCU | 抗静电ESD 8KV | -20~70℃ | 3.3v | ST7525 | |
| 192x64 COG点阵液晶屏/HTG19264A | COG | 192x64 |
|
106.49x46.66x5.2 | 102.89x36.06 | 97.486x32.462 | 0.508x0.458 | 6H | 白光 | FPC36PIN | MCU | 可配套铁框 | -20-70℃ | 3.3V | IST3020 | |
| 2.9寸 240X120 图形 COG LCD 模块 FSTN+ 显示屏，带白色背光 UC1608/HTM240120B-31W-N3P-V02 | COG | 240x120 |
|
84.0x50.0x6.6 | 72.0x37.0 | 67.17x33.57 | 0.28x0.28 | 12H | 背光颜色可选 | FPC-16PIN | MCU | 抗静电ESD 8KV | -20~70℃ | 3.3V | UC1608 | |
| 2.9寸240X120图形COG液晶模块 SPI FSTN+显示屏带白色背光/HTM240120B-31W-N3S-V01 | COG | 240x120 |
|
84.0x50.0x6.6 | 72.0x37.0 | 67.17x33.57 | 0.28x0.28 | 12H | 背光颜色可选 | FPC-16PIN | SPI | 抗静电ESD 8KV | -20~70℃ | 3.3V | UC1608 | |
| 2.6寸 240X160图形点阵COG液晶屏| FSTN+红绿蓝背光 | MCU接口 | Arduino HTG240160L-35S-18C10-V07 | COG | 240x160 |
|
60.0x49.5x5.6 | 56.0x38.7 | 51.94x34.62 | 0.216x0.216 | 6H | FPC-18PIN | MCU | 防静电ESD 8KV | -20~70℃ | +3.3 V | UC1698U | ||
| 2.6寸 240X160图形点阵COG液晶屏| FSTN+红绿蓝背光 | MCU 接口 | Arduino HTG240160L-35S-18C10-V07 | COG | 240x160 |
|
60.0x49.5x5.6 | 56.0x38.7 | 51.94x34.62 | 0.216x0.216 | 6H | FPC-18PIN | MCU | 防静电ESD 8KV | -20~70℃ | +3.3 V | UC1698U | ||
| 2.6寸 240X160图形点阵蓝底白字COG液晶屏| STN-LCD | MCU 接口 | Arduino HTG240160L-25W-18C10-V07 | COG | 240x160 |
|
60.0x49.5x5.6 | 56.0x38.7 | 51.94x34.62 | 0.216x0.216 | 6H | FPC-18PIN | MCU | 防静电ESD 8KV | -20~70℃ | +3.3 V | UC1698U | ||
| 2.6寸 240X160图形点阵蓝底白字COG液晶屏| STN-LCD | MCU接口 | Arduino HTG240160L-25W-18C10-V07 | COG | 240x160 |
|
60.0x49.5x5.6 | 56.0x38.7 | 51.94x34.62 | 0.216x0.216 | 6H | FPC-18PIN | MCU | 防静电ESD 8KV | -20~70℃ | +3.3 V | UC1698U |
