产品搜寻
| 勾选 | 型号 | 产品类型 | 显示内容 | 产品图 |
外形尺寸 (mm) |
视域窗口尺寸 (mm) |
显示尺寸 mm/英寸 |
点间距 mm |
视角 | 背光类型或亮度 | 连接方式PIN数 | 接口方式 | 特殊说明 | 工作温度 | 供电电压 | IC芯片型号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2.2寸128x64 COG LCD/128x64图形点阵COG LCD/DFSTN- 黑底白字/ST7567/Arduino HTG12864-20C-41W-28C05-V05 | COG | 128x64 |
|
53.2x37.8x2.8 | 49.2x27.0 | 40.92x24.28 | 0.38x0.32 | 6H | 白色 | FPC-28PIN | MCU | 防静电ESD 8KV | -20~70℃ | +3.3 V | ST7567 | |
| 2.2寸白底灰字点阵COG LCD/128x64COG点阵LCD显示屏/FSTN+/ST7567/Arduino HTG12864-20C-31W-28C05-V05 | COG | 128x64 |
|
53.2x37.8x2.8 | 49.2x27.0 | 40.92x24.28 | 0.38x0.32 | 6H | 白光 | FPC-28PIN | MCU | 防静电ESD 8KV | -20~70℃ | +3.3 V | ST7567 | |
| 2.2寸128x64 COG点阵LCD显示屏/黄绿色图形COG/STN+/ST7567控制器/Arduino HTG12864-20C-01Y-28C05-V05 | COG | 128x64 |
|
53.2x37.8x2.8 | 49.2x27.0 | 40.92x24.28 | 0.38x0.32 | 6H | 黄绿 | FPC-28PIN | MCU | 防静电ESD 8KV | -20~70℃ | +3.3 V | ST7567 | |
| 96x64COG点阵液晶屏/HTG9664F | COG | 96x64 |
|
28.0x22.3x1.7 | 25.0x15.3 | 23.02x14.06 | 0.24x0.22 | 6H | 白光 | FPC-18PIN | MCU | -20~70℃ | 3.3v | ST7549 | ||
| 3.3寸128x128 红绿蓝背光图形液晶LCD | FSTN+全透性点阵液晶显示屏 | Arduino HTG128128E-35S-31H07-V01 | COG | 128x128 |
|
66x71.5x4.85 | 60.0x59.6 | 55.02x55.02 | 0.43x0.43 | 6H | 红绿蓝 | FPC-31PIN | SPI | 防静电ESD 8KV | -20~70℃ | +3.3 V | SSD1848 | |
| 3.3寸128x128 蓝底白字图形液晶LCD | STN-全透性点阵液晶显示屏 | Arduino HTG128128E-25W-31H07-V01 | COG | 128x128 |
|
66x71.5x4.85 | 60.0x59.6 | 55.02x55.02 | 0.43x0.43 | 6H | 白色 | FPC-31PIN | SPI | 防静电ESD 8KV | -20~70℃ | +3.3 V | SSD1848 | |
| 3.3寸黄绿色128x128 COG图形液晶LCD | STN+点阵液晶显示屏 | Arduino HTG128128E-11Y-31H07-V0 | COG | 128x128 |
|
66x71.5x4.85 | 60.0x59.6 | 55.02x55.02 | 0.43x0.43 | 6H | 黄绿 | FPC-31PIN | SPI | 防静电ESD 8KV | -20~70℃ | +3.3 V | SSD1848 | |
| 3.3寸128x128 COG图形液晶LCD | STN+灰底蓝字点阵液晶显示屏 | Arduino HTG128128E-11W-31H07-V01 | COG | 128x128 |
|
66x71.5x4.85 | 60.0x59.6 | 55.02x55.02 | 0.43x0.43 | 6H | 白色 | FPC-31PIN | SPI | 防静电ESD 8KV | -20~70℃ | +3.3 V | SSD1848 | |
| 3.3寸128x128 图形COG液晶显示屏 | DFSTN-白底黑字点阵显示屏 | Arduino HTG128128E-41W-31H07-V01 | COG | 128x128 |
|
66x71.5x4.85 | 60.0x59.6 | 55.02x55.02 | 0.43x0.43 | 6H | 白色 | FPC-31PIN | SPI | -20~70℃ | +3.3 V | SSD1848 | ||
| 3.3英寸128x128 图形COG液晶显示屏 | FSTN+白底灰字COG | Arduino HTG128128E-31W-31H07-V01 | COG | 128x128 |
|
66x71.5x4.85 | 60.0x59.6 | 55.02x55.02 | 0.43x0.43 | 6H | 白色 | FPC-31PIN | SPI | 防静电ESD 8KV | -20~70℃ | +3.3 V | SSD1848 |
